0.1um Lab Benchtop 1L Planetary Ball Mill with Smart Panel

$ 42.94

10 items sold
Category:

Related products

    0.1um Lab Benchtop 1L Planetary Ball Mill with Smart Panel Applications: This laboratory 1L planetary ball mill is used in colleges and universities, scientific research units and enterprise laboratories to quickly grind research samples to colloidal fineness in batches, and then mix, homogenize and disperse. Widely used in geological, mining, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, beauty, environmental protection and other scientific research and industrial sectors. Introduction: Beautiful appearance, easy handling, fine grinding particle size, a good helper in the laboratory. It is used in colleges and universities, scientific research units and enterprise laboratories to quickly grind research samples to colloidal fineness in batches, and then mix, homogenize and disperse. Widely used in geological, mining, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, beauty, environmental protection and other scientific research and industrial sectors. CONTROL PANEL The panel has adjustment speed, grinding plan, start and stop emergency stop function, which can be adjusted according to your experimental requirements. FINE GRINDING Complete grinding methods, including dry grinding, wet grinding, high temperature grinding, low temperature grinding, vacuum grinding, protective atmosphere grinding, and the discharge particle size can reach 0.1 um. Highlight: 1. CE approved. The patented oil seal mute technology, PLC frequency conversion control, adopts the precision gear transmission designed by itself to replace the original belt transmission. 2. Two and four samples can be taken at a time, O-shaped sealed tank, safe operation, pressure resistance. 3. It is suitable for dry/wet/vacuum/protective atmosphere/low temperature/high temperature grinding to ensure the homogeneity and repeatability of the experiment and solve the deposition and adhesion problems of some materials. 4. The equipment is equipped with a safety switch and a safety automatic gear lock. There are universal wheels to push and run, and the equipment is safe and stable. 5. Low center of gravity, stable performance, compact structure, convenient operation, safe and reliable, low noise, no pollution, low loss. Technical Parameters of 1L Planetary Ball Mill: Product Name Lab Desktop 1L Planetary Ball Mill with Smart Panel Model BM-1L(Oil seal mute) Field of Application Pharmaceuticals, food, geology, metallurgy, agriculture, glass, ceramics, aviation chemicals, biology, materials, lithium power, electronics, plants, biology and so on. Feed Material Medium or low hardness, hard, brittle, fibrous, viscous. Size Reduction Principle Crushing, grinding, mixing, homogenization, alloying Main Disk Structure Planetary main disk gear invades and reinforces in lubricating oil, noise isolation treatment Standard CE Electrical Description 100-120V/200-240V AC ,50-60Hz, (0.55KW) Material Feed Size < 5 mm soil<10 mm Final Fineness < 100 nm Batch Size / Feed Quantity 4 x 250ml Grinding Jar Sizes 50 ml /100 ml/ 250ml Vacuum Jar Size 100ml( Stainless steel) Feed Material Capacity 83ml*4 Feed balls Capacity 83ml*4 Sun Wheel Speed 10 – 450 r/min Ball Mill Jar Speed 20 – 900 r/min Total Grinding Speed 1350 /min Speed Ratio 1:2 Material of Grinding Tools Stainless steel, agate, zirconia, corundum, tungsten carbide, nylon, polyurethane, polytetrafluoroethylene, silicon carbide, etc. Grinding Ball Ball Size: 1 / 2 / 3 / 5 / 8 / 10 / 15 / 20 / 25 / 30 mm Grinding Ball Selection: 1: Crushing Stage Matching 2: Grinding Stage Matching 3: Nano-dispersion (Due to the different material characteristics of each customer, please contact sales engineer for this selection.) No. of Grinding Stations 2 or 4 Mode Vertical planetary Grinding Mode Dry/wet Low Temperature Cooling Treatment Yes (air cooler added) Oil Seal Position The bottom of planetary main disk Disk Dimensions 265mm Oil Seal Capacity 800ml(fill in before using the planetary ball mill) Noise < 60dB(Within 3 metre） Protection Code IP60 CN Patent Safety protection (No.ZL 2015 2 0836150.6） CN Patent Oil seal silent (Patent No.ZL 2014 2 0375569.1） CN Patent Frequency control(patent No.ZL 2016 2 0836150.6） W x H x D Closed 550*370*560mm Net Weight 80kg Frequency Conversion Control System: The main functions of the planetary ball mill frequency conversion control system are as follows: 1. Forward operation: The planetary disk rotates clockwise. 2. Reverse rotation: The planetary disk rotates counterclockwise. 3. Alternate forward and reverse operation: The planetary disk rotates clockwise and counterclockwise alternately; the alternating forward and reverse operation can improve the uniform mixing and grinding effect of materials. 4. Forward and reverse alternate running time setting: You can set the forward running time and reverse running time. 5. Intermittent operation: The combined grinding method of static and grinding, this grinding method can properly precipitate and cool the material, which is very practical. 6. Intermittent running time setting: Set the static time and running time, which can be determined according to the nature of the material or experience. 7. Speed ​​adjustment: Adjustment of running speed, stepless speed regulation. 8. Running time setting: The setting of the total running time, the maximum duration is 9999 minutes, and the recommended duration is less than or equal to 100 hours. 9. Running: When running, the device works according to the set program. 10. Pause: Stop when running. 11. Power failure memory point recovery: This function is a special function of Miqi planetary ball mill, accidental power failure recovery memory, starting grinding from the power failure point. 12. Safety switch: On/off of the flip safety switch, after setting, it will not affect the normal operation of the device when the flip is opened or closed. 13. Restore settings: Can restore factory settings. After the control system program is set, the set function will be retained, and the next time it is turned on, it will run according to the last running program. Other Models: Model Voltage Motor power(KW) Inverter power KW Total timing (min) Alternating Run Time RPM Noise ≤db Revolution speed Rotation speed M-0.4L 220V 50HZ 0.55 0.55 1-9999 1-9999 5-450 10-900 《50db M-1L 220V 50HZ 0.55 0.55 1-9999 1-9999 5-450 10-900 《50db M-2L 220V 50HZ 0.75 0.75 1-9999 1-9999 5-400 10-800 《50db M-4L 220V 50HZ 0.75 0.75 1-9999 1-9999 5-400 10-800 《50db M-8L 220V 50HZ 1.5 1.5 1-9999 1-9999 5-320 10-640 《58db M -10L 220V 50HZ 1.5 1.5 1-9999 1-9999 5-320 10-640 《58db M -12L 380V 50HZ 1.5 2.2 1-9999 1-9999 5-320 10-640 《58db M-16L 380V 50HZ 2.2 2.2 1-9999 1-9999 5-280 10-560 《58db M-20L 380V 50HZ 3.0 3.7 1-9999 1-9999 5-230 10-460 《60db M-40L 380V 50HZ 5.5 7.5 1-9999 1-9999 5-220 10-440 《63db M-60L 380V 50HZ 7.5 7.5 1-9999 1-9999 5-180 10-360 《65db M-80L 380V 50HZ 7.5 11 1-9999 1-9999 5-180 10-360 《65db M-100L 380V 50HZ 11 11 1-9999 1-9999 5-180 10-360 《68db Matched Ball Mill Jars: Model Spec With ball mill jar Remarks Spec(ml) Quantities M-0.4L 0.4L 50-100ml 2 or 4 With 50ml vacuum ball mill jar M-1L 1L 50-250ml 2 or 4 With 50-100ml vacuum ball mill jar M-2L 2L 50-500ml 2 or 4 With 50-250ml vacuum ball mill jar M-4L 4L  50-1000ml 2 or 4 With100-500ml vacuum ball mill jar M-8L 8L 500-2000ml 2 or 4 With250-1000ml vacuum ball mill jar M-10L 10L 500ml-2.5L 2 or 4 With 250-2.5L vacuum ball mill jar M-12L 12L 1L-3L 2 or 4 With 500-3L vacuum ball mill jar M-16 16L 1L-4L 2 or 4 With 500-4L vacuum ball mill jar M-20L 20L 1L-5L 2 or 4 With 1000-5L vacuum ball mill jar M-40L 40L 4L-10L 2 or 4 With 3L-10L vacuum ball mill jar M-60L 60L 6L-15L 2 or 4 With 5L-15L vacuum ball mill jar M-80L 80L 6L-20L 2 or 4 With 5L-20L vacuum ball mill jar M-100L 100L 10L-25L 2 or 4 With 9L-25L vacuum ball mill jar Get In TouchFill out the form below — free quote and professional suggestion will be sent for reference very soon! Name Email* Message Send
